NEMA 4 Aluminum Junction Box 1414 N4 AL Series Lift Off Cover with Clamps
NEMA 4 Aluminum Junction Box 1414 N4 AL Series Lift Off Cover with Clamps
$136.22
Save
$-136.22
SKU: 1414N4ALA
Hammond Manufacturing
Size:
4 x 4 x 3 1414N4ALA
4 x 4 x 3 1414N4ALA
6 x 4 x 3 1414N4ALC
6 x 6 x 4 1414N4ALE
8 x 6 x 3.5 1414N4ALG
10 x 8 x 4 1414N4ALI
12 x 10 x 5 1414N4ALK
14 x 12 x 6 1414N4ALM6
16 x 14 x 6 1414N4ALO6
14 x 12 x 8 1414N4ALM8
16 x 14 x 10 1414N4ALO10
4 x 4 x 3 1414N4ALA - $136.22
6 x 4 x 3 1414N4ALC - $156.78
6 x 6 x 4 1414N4ALE - $175.05
8 x 6 x 3.5 1414N4ALG - $184.32
10 x 8 x 4 1414N4ALI - $216.54
12 x 10 x 5 1414N4ALK - $265.19
14 x 12 x 6 1414N4ALM6 - $322.39
16 x 14 x 6 1414N4ALO6 - $371.90
14 x 12 x 8 1414N4ALM8 - $366.02
16 x 14 x 10 1414N4ALO10 - $486.09
Description
Application
Designed for use as instrument enclosures, electric, hydraulic or pneumatic control housings, electrical junction boxes or terminal wiring enclosures.
Provides protection where equipment may be hosed down or otherwise be very wet, or in specific applications where corrosion is a problem.
Standards
UL 508A Type 4, 4X, 12 and 13
CSA Type 4, 4X, 12 and 13
Complies with
NEMA Type 4, 4X, 12 and 13
IEC 60529, IP66
Construction
Formed from 0.08" Type 5052 H-32 aluminum.
Smooth, continuously welded seams without knockouts, cutouts or holes.
Welded brackets provide for enclosure mounting.
Cover is secured with easily operated aluminum clamps.
Seamless poured-in place gasket.
All models larger than 4" x 4" include a removable 14 gauge inner panel.
Tapped studs are provided for mounting inner panels.
A bonding stud is provided on the door and a grounding stud is provided in the enclosure.
Finish
Cover and enclosure are natural unfinished aluminum.
Removable inner panel is finished in white powder coating.
