Application
- Designed for use as a junction or pull box.
Standards
- UL870 Type 1
- cUL Type 1
- Complies with
- NEMA Type 1
- IEC 60529, IP20
Construction
- Formed and spot welded from 16 gauge steel
- Mounting holes on back of enclosure
- Flat cover is secured with screws
- Two grounding point embosses on enclosure body
Finish
- Enclosure and cover are finished in ANSI 61 gray powder coating.
Part Details
Click part number for details (e.g., CAD files, assembly instructions, ship weight)
Units shown: inch. Switch units to: mm
| Enclosure | |||
|---|---|---|---|
| Part No. | H | D | L |
| CGT1244 | 4.00 | 4.00 | 12.00 |
| CGT1266 | 6.00 | 6.00 | 12.00 |
| CGT1844 | 4.00 | 4.00 | 18.00 |
| CGT1866 | 6.00 | 6.00 | 18.00 |
| CGT2444 | 4.00 | 4.00 | 24.00 |
| CGT2466 | 6.00 | 6.00 | 24.00 |
| CGT3644 | 4.00 | 4.00 | 36.00 |
| CGT3666 | 6.00 | 6.00 | 36.00 |
| CGT4844 | 4.00 | 4.00 | 48.00 |
| CGT4866 | 6.00 | 6.00 | 48.00 |
