Altelix 17x14x6 Vented Polycarbonate + ABS Weatherproof NEMA Enclosure with 100-240 VAC Universal Power Outlet

Altelix 17x14x6 Vented Polycarbonate + ABS Weatherproof NEMA Enclosure with 100-240 VAC Universal Power Outlet

Altelix SKU: NP171406VAU

$210.51

Lead Time: Estimated Lead Time Is 1-2 Business Days From Time Of Order Entry

Availability: Black & Light Ivory Are Temporarily Out Of Stock. All Other Colors Are In Stock As Of 12/4/24

Important: Lead times vary frequently! Please contact us with any questions and/or concerns. We may be reached directly through chat or email us at info@enclosurehub.com

Our business hours are Monday-Friday 7:30 AM - 4:30 PM EST. Orders will not be entered outside of business hours.

Features
  • Dual 3.5" Vents with Rain Shields to Expel Heat
  • Universal 100-240VAC Duplex Outlets
  • PC+ABS Polycarbonate / ABS Blend
  • Gasketed Lid with Tamper-Proof Locking Screw
  • Dual Door Latches
  • Includes Aluminum Equipment Mounting Plate
  • NEMA Type 3R, 3RX / IP24 Rated
  • Includes Wall Mount Hardware and Cable Grommets
 Applications
  • Worldwide Operation
  • Indoor / Outdoor WiFi Equipment
  • SCADA Remote Terminal Unit
  • Security and Surveillance Systems
  • Outdoor use of Indoor Equipment
  • Protection of Equipment from Theft or Damage
  • Concealment of Electronic Equipment



The Altelix NP171406VAU Vented Polycarbonate + ABS NEMA Weatherproof Enclosure with 100-240VAC Universal Power Outlet and Aluminum Equipment Plate is ideal for protecting equipment from harsh environments and tampering. This enclosure features a fully gasketed door to protect from dust and water ingress. The door features reinforced hinges, dual latches and a tamper-proof locking screw with key to secure the enclosure. There is also a provision for padlock use. Internal and external electrical ground points are also provided.

PC+ABS Polycarbonate / ABS Blend for Extreme Durability
These enclosures are molded out of UV resistant PC+ABS, a high tech thermoplastic blend of polycarbonate and ABS which combines the best qualities of both into a single material. PC+ABS enclosures are superior to ABS enclosures because they maintain high toughness, durability and dimensional stability even at extreme cold and hot temperatures.

Power
This enclosure features a 100-240VAC universal power outlet supporting multiple international power standards outside the USA.:

  • 110VAC 50/60Hz
  • 115VAC 50/60Hz
  • 220VAC 50/60Hz
  • 230VAC 50/60Hz
  • 240VAC 50/60Hz

Universal Power Outlet

The universal 100-240 VAC power outlet is compatible with the following plug types:

  • UK/Ireland BS 1363
  • Italy CEI 23-16/VII
  • Denmark Afsnit 107-2-D1
  • Euro plug (2-pin) CEE 7/16
  • Australia Type I
  • India BS 546

For the following plugs types, please refer to the safety notes in the Technical Specs:

  • Swiss (2-pin) SEV 1011
  • Israel SI 32
  • North America (2-pin) NEMA 1-15 and (3-pin) NEMA 5-15
  • Continental Europe (Schuko) CEE 7
  • France/Belgium CEE 7

A ground lug is provided and one cable gland for the AC supply. Knock-outs are provided on the enclosure for additional wiring. Cable grommets are included with the accessory kit.

Ventilation
This enclosure features two 3 inch air vents. Rain shields help prevent rain water from entering the enclosure.

Aluminum Equipment Mounting Plate
The enclosure and plate can be drilled and modified by the installer to suit unique site requirements.

Mounting
The enclosure can be wall mounted using the included wall anchors. An optional pole mount kit is also available for installation on poles up to 8 inches in diameter. See the accessories section above.

*Interior dimensions represent maximum space available for equipment.


**Safety Notes:
  1. In some countries (Swiss, Israel, and North America) there may be polarity differences. To avoid possible damage to a device, check the polarity of your power supply and that of your device before plugging it in to the Universal AC outlet and switching it on.
  2. Some devices require they be grounded. Use caution with plugs from Continental Europe (Schuko) and France/Belgium for the Universal AC outlet does not allow for the grounding tabs or grounding pin.



Material PC+ABS Polycarbonate / ABS Blend
Available Colors Gray, Black, Light Ivory, OD Green
Voltage 110VAC 50/60Hz
115VAC 50/60Hz
220VAC 50/60Hz
230VAC 50/60Hz
240VAC 50/60Hz
Universal Outlet Compatibility UK/Ireland BS 1363
Italy CEI 23-16/VII
Denmark Afsnit 107-2-D1
Euro plug (2-pin) CEE 7/16
India BS 546
Australia Type I
Swiss (2-pin) SEV 1011**
Israel SI 32**
North America (2-pin) NEMA 1-15**
North America (3-pin) NEMA 5-15**
Continental Europe (Schuko) CEE 7**
France/Belgium CEE 7**
Outer Dimensions 16.5 x 13.7 x 6.7 Inches
(420 x 348 x 167 mm)
Inner Dimensions* 11.5 x 9.0 x 4.0 Inches
(292 x 229 x 102 mm)
Mounting Plate Material 0.08 in (2.0 mm) Aluminum
Mounting Plate Dimensions 14.9 x 11.2 in. (378 x 285 mm)
Weight 6.8 lbs. (3.0 kg)
Ratings NEMA Type 3R, 3RX / IP24
Flame Rating Meets UL94-V0
Knockout Sizes (Diameter) (4) 0.62 in. (16 mm)
(4) 1.02 in. (26 mm)
(4) 1.30 in. (33 mm)
