Type 4X Aluminum Junction Box Eclipse Junior Series Continuous Hinge Door with Quarter Turn

Type 4X Aluminum Junction Box Eclipse Junior Series Continuous Hinge Door with Quarter Turn

Hammond Manufacturing SKU: EJ443AL

$136.88

Lead Time: All Hammond products vary, we can find this information quickly for you.

Availability: In stock products will ship within 1-2 business days.

Please chat with us directly or email at info@enclosurehub.com and we can give you the most accurate and up-to-date information.

Our business hours are Monday-Friday 7:30 AM - 4:30 PM EST. Orders will not be entered outside of business hours.


Application

  • Designed for use as instrument enclosures, electric, hydraulic or pneumatic control housings, electrical junction boxes or terminal wiring enclosures.
  • Provides protection where equipment may be hosed down or otherwise be very wet, or in specific applications where corrosion may be a problem.

Standards

  • UL 508A Type 3R, 4, 4X, 12, and 13
  • CSA Type 3R, 4, 4X, 12, and 13
  • Complies with
    • NEMA Type 3R, 4, 4X, 12 and 13
    • IEC 60529, IP66

Construction

  • Formed from 0.08" Type 5052 H-32 aluminum.
  • Smooth, continuously welded seams without knockouts, cutouts, or holes.
  • Formed lip on enclosure to exclude flowing liquids and contaminants.
  • Welded brackets provide for enclosure mounting.
  • Continuously hinged cover has aluminum hinge and provides 180° opening.
  • Door latches feature the added safety of quarter turn slot requiring use of tool for opening.
  • Quarter turn latches formed from 316 stainless steel.
  • Seamless poured-in place gasket.
  • Models larger than 4"x4" include a removable 14 gauge galvanized inner panel.
  • Tapped studs are provided for mounting inner panels.
  • A bonding stud is provided on the door and a grounding stud is provided on the enclosure.
  • Grounding and panel mounting hardware provided.

Finish

  • Cover and enclosure are natural unfinished aluminum.
  • Removable inner panel is unpainted galvanized steel.

Videos

Accessories

Part Details

Click part number for details (e.g., CAD files, assembly instructions, ship weight)

Units shown: inch. Switch units to: mm

Enclosure Panel
Part No. H W D H W
EJ443AL 4.00 4.00 3.00 N/A N/A
EJ643AL 6.00 4.00 3.00 4.88 2.88
EJ863AL 8.00 6.00 3.50 6.75 4.88
EJ444AL 4.00 4.00 4.00 N/A N/A
EJ644AL 6.00 4.00 4.00 4.88 2.88
EJ664AL 6.00 6.00 4.00 4.88 4.88
EJ884AL 8.00 8.00 4.00 6.75 6.88
EJ1084AL 10.00 8.00 4.00 8.75 6.88
EJ1264AL 12.00 6.00 4.00 10.75 4.88
EJ12124AL 12.00 12.00 4.00 10.75 10.88
EJ12105AL 12.00 10.00 5.00 10.75 8.88
EJ866AL 8.00 6.00 6.00 6.75 4.88
EJ1086AL 10.00 8.00 6.00 8.75 6.88
EJ10106AL 10.00 10.00 6.00 8.75 8.88
EJ12106AL 12.00 10.00 6.00 10.75 8.88
EJ12126AL 12.00 12.00 6.00 10.75 10.88
EJ14126AL 14.00 12.00 6.00 12.75 10.88
EJ16146AL 16.00 14.00 6.00 14.75 12.88
EJ12108AL 12.00 10.00 8.00 10.75 8.88
EJ14128AL 14.00 12.00 8.00 12.75 10.88
EJ16148AL 16.00 14.00 8.00 14.75 12.88
EJ161410AL 16.00 14.00 10.00 14.75 12.88
